Aerial Working Truck

Description:
This truck can be used in various industries which need high work above the ground, such as electric power, street lamp, municipal administration, garden, communication, airport, shipbuilding, ship repairing, transportation, advertising, photography, etc.

The type of this aerial working truck includes vertical lifting type, folding boom type, self-traveling type, telescopic boom type.

The working height of this vehicle can be 6m, 10m, 14m, 16m, 18m, 22m, 25m, 30m, 50 m.

Typical: Dongfeng Tianjin Aerial Working Truck 20~22m

Application:
Dongfeng Tianjin aerial working truck can be used in various industries which need high work above the ground, such as electric power, street lamp, municipal administration, garden, communication, airport, shipbuilding, ship repairing, transportation, advertising, photography, etc. It is the ideal vehicle in power maintenance, street signs installation of municipal administration, power supply, traffic management and others.

Feature:
1. Dongfeng Tianjin aerial working truck is made from DFL1120B chassis.
2. Due to many advanced operation safety functions, it can ensure the safety of operating personnel.
3. The control devices are equipped with working slot and rotation seat. You can control the start/stop on the engine. The working speed can also be controlled;
4. Working arm can rotate 360 ° to the left or right continuously.

5. It has lighting at night. The lifting weight can reach 2t.

Parameters

Item Dongfeng Tianjin Aerial Working Truck
Lifting height 20~22m
Lifting weight 2T
Install type Three folding sections
Supporting leg number 4
Exemption notice 18th book(2009 the third edition ) Click Page 12 for Inquiry
Vehicle production announcement 228th, click here for inquiry

Special Function of Dongfeng Tianjin Aerial Working Truck

Cab 6 × 2 drive, D530 cab, front width 860 mm, rear width 860 mm, electrical heating cold starting device, whole steel 160L fuel tank, Φ 350 mm push diaphragm spring clutch, Dongfeng DF6S750 gearbox with 6 grade, automatic adjustable arm, no ABS, electric glass lifts, central door lock, standard refrigeration and air conditioner, no cruise system, remote throttle interface and PtO interface.
Cotrol system The hydraulic motor components of control system is from American Eaton; balancing valve is from Danish; the sealing ring is produced in Taiwan multiple valve is imported from Turkey; the other accessories, such as hydraulic cylinder, hydraulic lock are all from well-known brands in domestic.
Safety system The main stress-taking parts are made of manganese steel from WUHAN STEEL AND IRON CORP. The quality is reliable. Other control elements can realize free operation. The engine has emergency flameout and restarts function; the operator can get on the vehicle from the working platform, turntable table and the ground. It can ensure the employees operating safety.
Paint The body and other metal attachments is sprayed anti-corrosion paint. The paint is high adhesion; even paint film, light color lasting, etc. It can bear damp, dusty, salt fog and other bad environment. And it will not craze, peeling, fade.
Body colour Blue, white, yellow; we can design the special apperance according to your requirements.
FUNCTION Max working height 20~22m Max working distance 8.5m
Rated load of bucket 200kg Rotation angle 360°
Rotation speed 0~2r/min Rated lifting quality 2000kg(optional)
Max lifting height 8.8m(optional) Up, middle, down operation (optional)
Longitudinal span of supporting leg 3.25m Horizontal span of supporting leg 3.4m
Bucket size 1.1×0.63×1.05m
