Water Tank Truck Description:
This vehicle is suitable for cleaning all kinds of roads, pavement, guardrail, trees, green belts, lawn green, mines construction, high altitude building, etc. In addition, it can be used to spray pesticide and temporary emergency fire fighting sprinkler.
DongFeng Xiaobawang Water Tank Truck 4T
Special Function:
1. The body is made of high quality carbon steel;
2. The inside of the body is shock wave reducing clapboard;
3. The high pressure gas leakage detection test is used;
4. The sprinkles special pump is installed;
5. The water-spraying shape an be adjusted into heavy rain, light rain, mist effect;
6. It has two water pipes, electronic music speakers and fire control interface.
Technical Parameters
| Item | Water Tank Truck/ Firefighting Water Truck | Overall dimension(mm) | 5980×1980×2180 |
| Overall dimension | EQ1060TJ20D3 | Body dimension(mm) | ×× |
| Body dimension | 6495 | Approach angle/departure angle(°) | 19/15 |
| Body volume | 3350,3415 | Front overhang/rear overhang (mm) | 1032/1488 |
| Rated quality | 2950 | Max. speed(km/h) | 90 |
| Item | 2595/3900 | ||
| Chassis Technical Parameters of Dongfeng Xiaobawang Water Tank Truck | |||
| Chassis model | EQ1060TJ20D3 | Batch | 218 |
| Axles number | 2 | Fuel type | Diesel |
| Axle distance(mm) | 3300 | Front wheel base(mm) | 1506 |
| Passenger number in cab | 2,3 | Back wheel base(mm) | 1466 |
| Tyre number | 6 | Spring number | 8/9+5,6/8+4 |
| Tyre size | 7.00-16,6.50-16,7.00R16,6.50R16 | ||
| Vehicle introduction | Body volume: 3.5m3; the body size: 3500mm×1620mm×920mm. | ||
| Engine Parameter of Dongfeng Xiaobawang Water Tank Truck | |||
| Engine type | Engine manufacturer | Displacement(ml) | Power(kw) |
| YC4F90-30 CY4102-C3F YN27CR YN30CR SD4BW70-3R 4D22E YCND27-90-30 YCND27-100-30 CY4100-E3F 4JB1TI | Guangxi Yuchai Machinery Co., Ltd Dongfeng Chaoyang Diesel Engine Co., Ltd Chengdu Yunnei Power Co., Ltd. Chengdu Yunnei Power Co., Ltd. Jiangsu Sida Power Co., Ltd. Anhui Quanchai Power Co., Ltd. Guangxi Yuchai Machinery Co., Ltd Guangxi Yuchai Machinery Co., Ltd Dongfeng Chaoyang Diesel Engine Co., Ltd Chengdu Yunnei Power Co., Ltd. | 2659 3856 2672 2977 2545 2156 2659 2659 3707 2771 | 66 70 66 76 70 65 66 75 73 75 |
