Description:
This truck can be widely used in all kinds of loading and unloading operation related to lifting work. It is especially suitable to the lifting work on the outdoors, the emergency task and narrow workplaces, such as station, port, warehouse, building site. The main models of truck with loading crane in our company include Dongfeng series and Jiefang series. Dongfeng series truck with loading crane also include various types, such as Dongfeng Xiaobawang, Dongfeng Dajingang, Dongfeng 140, Dongfeng 145, Dongfeng Tianjing, Dongfeng 153, Dongfeng Shuangjin, Dongfeng Tianlong, etc.
Feature:
1. This truck with loading crane adopts famous cranes and hydraulic pump system. You can choose various cranes or compartments with different length and tonnage according to your requirements.
2. The truck with loading crane has the advantages of large power, high speed, great slope climbing ability, high hoisting height, and wide work range, etc.
3. It can lift quickly, which can achieve the energy conservation. In addition, this truck with loading crane is flexible, convenient, safe and reliable.
EQ1258KB3GJ1 Truck with Loading Crane (Dongfeng Houshuangqiao)
Model:Description:
EQ1258KB3GJ1 truck with loading crane can be widely used in all kinds of loading and unloading operation related to lifting work. It is especially suitable to the lifting work on the outdoors, the emergency task and narrow workplaces, such as station, port, warehouse, building site. The main models of truck with loading crane in our company include Dongfeng series and Jiefang series. Dongfeng series truck with loading crane also include various types, such as Dongfeng Xiaobawang, Dongfeng Dajingang, Dongfeng 140, Dongfeng 145, Dongfeng Tianjing, Dongfeng 153, Dongfeng Shuangjin, Dongfeng Tianlong, etc.
Feature:
1. EQ1258KB3GJ1 truck with loading crane adopts famous cranes and hydraulic pump system. You can choose various cranes or compartments with different length and tonnage according to your requirements.
2. EQ1258KB3GJ1 truck with loading crane has the advantages of large power, high speed, great slope climbing ability, high hoisting height, and wide work range, etc.
3. EQ1258KB3GJ1 truck with loading crane can lift quickly, which can achieve the energy conservation. In addition, this truck with loading crane is flexible, convenient, safe and reliable.
| Technical Parameters | |||
| Item | Dongfeng Houshuangqiao Truck with Loading Crane | Overall dimension(mm) | 11945,11100×2500×3850,3750 |
| Chassis model | EQ1258KB3GJ1 | Body dimension(mm) | 8500,8200,7700,7500×2294×550,800 |
| Total mass(kg) | 25000 | Approach angle/departure angle(°) | 32/13,32/12 |
| Rated quality (kg) | 12000,12120 | Front overhang/rear overhang (mm) | 1245/2845,1245/2795,1245/2315, 1245/2265,1245/3205,1245/3155 |
| Kerb weight (kg) | 12805,12685 | Max. speed(km/h) | 85 |
| Axle load | 7000/18000(with double axles) | ||
| Chassis Technical Parameters of EQ1258KB3GJ1 Truck with Loading Crane | |||
| Chassis model | EQ1258KB3GJ1 | Batch | 199 |
| Axles number | 3 | Fuel type | Diesel |
| Axle distance(mm) | 5370+1300,5900+1300,5370+1350, 5900+1350 | Front wheel base(mm) | 1940 |
| Passenger number in cab | 3 | Back wheel base(mm) | 1860/1860 |
| Tyre number | 10 | Spring number | 8/13,8/12 |
| Tyre size | 10.00-20,11.00-20,10.00R20,11.00R20 | ||
| Vehicle introduction | The crane type, quality (Kg), maximum lifting load (Kg), curbs weight (Kg), rated load weights (Kg) are respectively SQ10S:2820/10000/12805/12000; SQ8S:2700/8000/12685/12120. The cab selection depends on the chassis. If the vehicle length is 11945mm, the corresponding wheelbase should be 5900 + 1300mm. The corresponding rear suspension should be 3500mm; if the vehicle length is 11100mm, the corresponding wheelbase should be 5370 + 1300mm; the corresponding rear suspension should be 3185mm. | ||
| Engine Parameter of EQ1258KB3GJ1 Truck with Loading Crane | |||
| Engine type | Engine manufacturer | Displacement(ml) | Power(kw) |
| B220 30 B210 33 | Dongfeng Cummins Engine Co., Ltd. | 5900 5900 | 162 155 |
