Feature
1. The anti-overflow device is installed in this vehicle, which can prevent the waste and sewage flow backward to vacuum pump system.
2. The shape of this fecal sucking vehicle/sewage sucking vehicle is similar to the tortoise back. It will not be deformation permanently.
3. The vacuum sewage-sucking pump is from Hangzhou Weilong. This pump has the features of high vacuum degree, far sucking distance, etc.
4. The sewage-sucking tube can rotate 360 degrees.
5. We can add water spraying function on this vehicle.
| EQ1168KJ Fecal Sucking Vehicle/Sewage Sucking Vehicle |
| 1. The anti-overflow device is installed in this vehicle, which can prevent the waste and sewage flow backward to vacuum pump system. 2. The shape of this EQ1168KJ fecal sucking vehicle/sewage sucking vehicle is similar to the tortoise back. It will not be deformation permanently. 3. The vacuum sewage-sucking pump is from Hangzhou Weilong. This pump has the features of high vacuum degree, far sucking distance, etc. 4. The sewage-sucking tube can rotate 360 degrees. 5. We can add water spraying function on this vehicle. |
| Item | Fecal Sucking Vehicle/Sewage Sucking Vehicle | Overall dimension(mm) | 7800×2470×3150 |
| Chassis model | EQ1168KJ | Body dimension(mm) | ×× |
| Total mass(kg) | 16000 | Approach angle/departure angle(°) | 25/18 |
| Rated quality (kg) | 8000 | Front overhang/rear overhang (mm) | 1205/1895 |
| Kerb weight (kg) | 7805 | Max. speed(km/h) | 90 |
| Axle load | 6000/10000 | ||
| Chassis Technical Parameters of EQ1168KJ Fecal Sucking Vehicle/Sewage Sucking Vehicle | |||
| Chassis model | EQ1168KJ | Batch | 215 |
| Axles number | 2 | Fuel type | Diesel |
| Axle distance(mm) | 4500 | Front wheel base(mm) | 1940 |
| Passenger number in cab | 3 | Back wheel base(mm) | 1860 |
| Tyre number | 6 | Spring number | 8/10+8 |
| Tyre size | 10.00-20,10.00R20 | ||
| Vehicle introduction | The body volume is 12.0m3. Its size is (mm):5100×2350×1500. the cab selection is based on the chassis. | ||
| Engine Parameter of EQ1168KJ Fecal Sucking Vehicle/Sewage Sucking Vehicle | |||
| Engine type | Engine manufacturer | Displacement(ml) | Power(kw) |
| ISBE185 30 ISDe180 30 ISDe185 30 ISDe210 30 B190 33 |
Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. |
5900 4500 6700 6700 5900 |
136 132 136 155 140 |
