Garbage Truck

Garbage Truck

Description:
This product refers to a truck specially designed to collect small quantities of waste and haul the collected waste to a solid waste treatment facility. In the United States it can also be called trash truck, dump truck, dustcart, dustbin lorry, bin lorry. Technically, this garbage truck can be called waste collection vehicle and refuse collection vehicle.
Application:
The garbage truck can be widely applicable to the environmental sanitation, municipal administration, industrial and mining enterprises, property community, and the residential areas with large mount of garbage. One garbage truck can hold several garbage compartments; it can effectively avoid secondary pollution in loading and unloading process.
Features:
The garbage truck has the features of simple structure, stable operation, high efficiency of garbage loading and unloading, high mechanization, labor save, etc. The modified parts can be separated with the original truck chassis. It is convenient to maintenance. The original mobility and driving performance of the truck can be kept.

Typical EQ5140KLJ Garbage Truck (Dongfeng 153)

Description:

The EQ5140KLJ garbage truck can be widely applicable to the environmental sanitation, municipal administration, industrial and mining enterprises, property community, and the residential areas with large mount of garbage.
Feature:
1. One EQ5140KLJ garbage truck can hold several garbage compartments; it can effectively avoid secondary pollution in loading and unloading process.
2. The modified parts can be separated with the original truck chassis. It is convenient to maintenance. It can effectively avoid secondary pollution in loading and unloading process.
3. The EQ5140KLJ garbage truck in our company has the features of simple structure, stable operation, high efficiency of garbage loading and unloading, high mechanization, labor save, etc. In addition, we also provide other types of garbage trucks, such as Dongfeng Xiaobawang, Dongfeng Duolika, Dongfeng 140, Dongfeng 145, Dongfeng 153, etc. The users can bring their own chassis; our factory provides production modification of other parts. If you have special requirements towards the garbage truck, please contact us for free. We can design and modify according to your requirements. Meanwhile, the direction assistance component and air conditioner can be added

Technical Parameters
Item Dongfeng 153 Compression garbage truck Overall dimension(mm) 8380,8150×2500×3320
Chassis model EQ5140KLJ Body dimension(mm) ××
Total mass(kg) 14490 Approach angle/departure angle(°) 25/23,25/21,14/23
Rated quality (kg) 5000 Front overhang/rear overhang (mm) 1250/1890,1250/2250
Kerb weight (kg) 9295 Max. speed(km/h) 90
Axle load 4990/9500
Chassis Technical Parameters of EQ5140KLJ Garbage Truck
Chassis model EQ5140KLJ Batch 188
Axles number 2 Fuel type Diesel
Axle distance(mm) 4500 Front wheel base(mm) 1940
Passenger number in cab 3 Back wheel base(mm) 1860
Tyre number 6 Spring number 8/10+8
Tyre size 10.00-20
Vehicle introduction The selection of bumper on the front of truck depends on the chassis (only the lighting changes). This EQ5140KLJ garbage truck has no rear dumping gear. Therefore, the length of the truck is 8150mm. and the corresponding rear overhang is 2400mm.
Engine Parameter of EQ5140KLJ Garbage Truck
Engine type Engine manufacturer Displacement(ml) Power(kw)
ISDe185 30 ISDe210 30 YC6J180-30 ISDe180 30 YC6J180-33
B190 30
B190 33
Dongfeng Cummins Engine Co., Ltd.
Dongfeng Cummins Engine Co., Ltd.
Guangxi Yuchai Machinery Co., Ltd
Dongfeng Cummins Engine Co., Ltd.
Guangxi Yuchai Machinery Co., Ltd
Dongfeng Cummins Engine Co., Ltd.
Dongfeng Cummins Engine Co., Ltd.
6700
6700
6500
4500
6494
5900
5900
136
155
132
132
132
140
140
