Cargo Truck

Description:
Cargo truck is a engineering trailer that used for transport heavy cargo with serious wheels. This truck is equipped with single-axle leading truck to run smoothly. The truck adopts more Locomotive wheels with smaller diameter then that of passenger truck. And the cylinder inside is bigger generally to create lager traction force.
CAMC 6×4 Standard Model Cargo Truck

Product Name Cargo Truck
Product Model HN1250
Place of Origin Maanshan, Anhui, China
G.V.W 25 ton
Kerb mass 11 ton
Payload 14 ton
Drive Type Left Hand only
Drive Model 6×4
Engine Brand CUMMINS
Model C300 20
Max. Power (kw/r/min) 221/2200
Displacement 8300ml
Emission Standard Euro II
Clutch Model Φ430 diaphragm spring
Transmission Brand FAST GEAR
Model 9JS135T
Rear Axle(drive axle) Model HL457
Front Axle-load 6.5 ton
Cabin Type Classic flat roof
Cabin With A/C, Radio, Bunk
Steering System HITACHI
Wheelbase (mm) 5220+1350
Tire Type Bias/Radial
Model 11.00-20/11.00R20/12.00-20/12.00R20
Tire number 10+1
Oil Tank Volume(L) 320
Dimensions(L×W×H) Overall (mm) 11880×2495×3130
Body interior (mm) 8500×2300×800
Front overhang/Rear overhang(mm) 1370/2980
Approach/Departure Angle(°) 25/15
No. of steel spring(front/rear) 9/12
Max. Speed (km/h) 78

Remarks: Due to improvements made to the product, data herein is subject to change without notice. Different outfits are provided for the different configurations of the motor vehicles. Affected by the reproduction conditions, the pictures and data differ somewhat from the actual motor vehicles. CAMC reserves the rights to make final explanations.
