Dump Truck DONGFENG 7T

Dump Truck DONGFENG 7T

Dumper model: HN3250P34C6M

Description:

Cabin: Mitsubish style or Euro style, flat roof; With air conditioner, MP3 or CD player and sleeper., etc.
Engine: Cummins, HINO, Mitsubish, Weichai., etc.
Engine power Range: 230HP~400HP
Engine Emission Standard: Euro 2 or 3
Fuel Type: Diesel oil
Transmission: Fuller 9/12/16 shifts; ZF 16 shifts
Weelbase(mm): 3600+1350

Overall Dimention(mm)
Lenghth: 8080
Width: 2495
Height: 3200
DECK Dimension(mm)
Lenghth: 5000; 5400; 5600; 6500
Width: 2300
Height: 1100; 1200; 1300; 1400; 1500
Tire specification(optional): 11.00-20; 11.00R20; 12.00-20; 12.00R20; 12.00-24; 12.00R24; 12R22.5; 315/80R22.5., etc.
Number of Axles: 3 Number of Tire: 10+1
Color(optional): White; Blue; Red; Yellow., etc.
Steering Model: Steering wheel

Driving Model: Left-hand or right-hand
GVW(kg): 25000
Kerb Mass(kg): 12455
Rated loading Capacity(kg): 15000~25000
Approaching Angle/Departure Angle(degree): 25/24
Rated Crew(including Driver): 3
Front Suspension/Rear Suspension(mm): 1370/1760
Max. Speed(km/h): 90
Remaks: We can produce the truck you need according to your special requirement
