Jaw Crusher

Product Introduction
MITG PE series jaw crusher, as one important stone jaw crushing machine in the crushing line, is based on a forward-looking idea of making our users enjoy great variety-both casting and welded frame construction. The design of this jaw crusher (stone jaw crushing machine) offers owners the highest possible fatigue strength, excellent reliability and numerous mounting possibilities. This, combined with special high-quality cast steel components and very durable wear parts, means exceptionally high crusher availability, cost-efficient crushing and low cost per ton.
Every MITG jaw crusher is a product of know-how and experience optimized by Finite Element Analysis (FEY). Each model is tested virtually for stress, strain, shock, deformation, thermal loading, vibration and noise under a wide range of load conditions. The result is exceptional reliability.
Features of Our Jaw Crusher
•  High reliability
•  both casting and welded frame construction
•  Top crushing performance
•  Wedge setting adjustment
•  This jaw crusher is fast and simple maintenance
•  Easy and less costly to install
•  Excellent total crushing economy
•  A stone jaw crushing machine with excellent suitability
•  Highly versatile: Ready and able to crush all your tons
 Our jaw crusher can be in stationary or semi-mobile installations
Jaw Crusher Operating Principle:
This jaw crusher uses motor as its power. Through the motor's wheels, the eccentric shaft is driven by the triangle belt and slot wheel to make the movable jaw plate move by a regulated track. Therefore, the materials in the crushing cavity of this stone jaw crushing machine composed of fixed jaw plate, movable jaw plate and side-lee board can be crushed and discharged through the discharging opening.

Model of jaw crusher Size of feed opening
(mm × mm)
Max. feed size(mm) Capacity
(t/h)
Adjustable range of discharge opening(mm) Power
(kw)
Weight
(t)
Dimension
(mm)
PE-250×400 250×400 210 5-20 20-60 15 2.8 1450×1315×1296
PE-400×600 400×600 340 16-65 40-100 30 6.5 1565×1732×1586
PE-500×750 500×750 425 45-100 50-100 55 10.1 2365×1911×2062
PE-600×900 600×900 500 50-120 65-160 55-75 15.5 2536×1877×2340
PE-750×1060 750×1060 630 52-180 80-140 110 28 2450×2410×2860
PE-800×1060 800×1060 650 85-143 100-200 110 30 2660×2556×2800
PE-870×1060 870×1060 670 181-210 200-260 110 30.5 2733×2556×2800
PE-900×1200 900×1200 750 140-360 95-165 110 50 3558×2875×3268
PE-1000×1200 1000×1200 850 160-420 195-265 110 51 3558×2875×3268
PE-1200×1500 1200×1500 1020 400-800 150-300 180 100.9 4200×3732×3843
