GR135 Motor Grader

GR135 Motor Grader

Basic specification
Engine model 6BT5.9
Rated power/speed 100/2200kw/rpm
Dimension(L×W×H) 8015×2380×3050mm
Operating weight(Standard) 11000kg
Performance specification
Travelling speed, forward 5, 8, 13, 20, 30, 42km/h
Travelling speed, reverse 5, 13, 30km/h
Tractive force(f=0.75) 61.3KN
Max. gradeability 20%
Tire inflation pressure 300kPa
Working hydraulic pressure 16MPa
Transmission pressure 1.3~1.8MPa
Operating specification
Max. steering angle of front wheels ±49°
Max. lean angle of front wheels ±17°
Max. oscillation angle of front axle ±15°
Max. oscillation angle of balance box 16
Frame articulation angle ±27°
Min. turning radius using articulation 6.6m
Maximum lift above ground 410mm
Maximum depth of cutting 535mm
Maximum blade position angle 90°
Blade cutting angle 28°—70°
Circle reversing rotation 360°
Moldboard width × height 3710×610mm
