Feeding Technology: reliable and endurable
Large range of the
clearance adjusting of the separate rod (330-480mm) meets the requirements of
different paving conditions and reduces the segregation along the height
direction.
It adopts Φ420X360 large diameter and coarse pitch blade,
reducing the rpm and segregation.
Two reverse blades in material separate
box reduce the medium segregation area.
Center Cooling Technology: advanced and unique
With the
optimized configuration and optimal cooling performance, the combined cooling
water tank is 50% large than the standard water tank of the diesel engine, which
could ensure the machine working constantly in high temperature.
The diesel
engine and the cooling system adopt the unique closing structure.
The heat of
the machine is discharged forcefully.
Screed Technology: mature and reliable
The most mature and
reliable screed
The screed devices are of many kinds and multiple functions,
and the optimal screed is selected according to the requirement of the user.
Dual-vibrating mechanisms could get the excellent compaction on the
stabilized material.
The stepless and adjustable vibrating frequency could
meet the requirements of various conditions.
Electric heating or gas heating
is selected according to the requirement of the user.
Precise Allocation
The key parts adopt the high strength
materials: the bottom plate and protective devices adopt the imported high
endurance steel plate from Germany.
High reliable power and transmission.
RP951A/RP902 is equipped with Deutz BF6M1013E engine, 137KW; RP952 is
equipped with Shangchai D6114 diesel engine, 140kW; and the optimal is162kW.
They could meet the requirements of different users.
Advanced Technology
Triune travel and drive device features high
reliability and convenient service.
One machine, multiple applications. It
can pave the asphalt mixture, lime-flyash soil and stabilizing soil.
Simple Operation
The control system adopts micro-computer
controlling, featuring simplicity and convenience.
All control components
are installed on the instrument box, easy to access.
The seat could be moved
to outside featuring excellent visibility.
Easy Maintenance
Integrated lubrication device prolongs the service
life of the bearings on the positions in high temperature, and reduces the
maintenance work.
The diesel engine hood adopts the spring lifting, which is
easy for service; the cabin adopts the spring to descend and lift up, which is
easy for transportation.
The side hood and diesel engine hood are easy to
open, and the components often maintained are easy to access.
The
pressure-testing points are distributed reasonably, and easy and rapid to
measure.
| Item | Unit | RP902 |
| Basic Paving Width | m | 3 |
| Max Paving Width | m | 9 |
| Max Paving Thickness | mm | 350 |
| Paving Speed | m/min | 0~18 |
| Travel Speed | km/h | 0~2.2 |
| Theoretical Productivity | t/h | 700 |
| Capacity | t | 14 |
| Hopper Capacity | % | 20 |
| Gradeability | mm/3m | ≤2 |
| Pavement Evenness | % | ±0.02 |
| Transverse Leveling Accuracy | % | -1~3 |
| Centre Crown Ratio | BF6M1013E | |
| Engine Model | kw | 137 |
| Engine Power | r/min | 2300 |
| Engine Speed | L | 270 |
| Diesel Tank Capacity | t | 23.8~28.6 |
| Machine Weight | Hz | 0~50 |
| Tamper Vibration Frequency | Electric Heating | |
| Screed Heating | Automatic Control by Ultrasonic Sensors | |
| Auger and Conveyor Control | Digital | |
| Automatic Leveling Control |
| Screed model | Type | Stretching method | Width range | Vibrating speed | Main amplitude | Auxiliary amplitude |
| DTV-I(RP951A) | Dual-vibrating, eccentric vibrating, electric heating | Mechanical assembly | 3.0-9.5m | 0-1470r/min | 3, 5, 7, 9 mm | 0, 3, 6, 9, 12 mm |
| DTQ-I(RP952) | Dual-vibrating, gas heating | Mechanical assembly | 3.0-9.5m | 0-1470r/min | 3, 5, 7, 9 mm | 0, 3, 6, 9, 12 mm |
| EDV60D(RP902) | Dual-vibrating, eccentric vibrating, electric heating | Hydraulic variomatic | 3.0-9.5m | 0-1470r/min | 5mm | 0, 5, 10 mm |
