Description
LTJ18X21 road rollers are heavy-duty static three wheel road rollers. With their dead weight, the static road rollers compact cohesive and non-cohesive materials, such as gravel, sand stone mixture, sandy soil and asphalt concrete. LTJ18X21 static three wheel road roller is multifunction compacting equipment used for medium and large-scale construction projects, such as highway, municipal road, parking area and industry ground.
Main Features of LTJ18X21 Static Road Rollers
1. With stable quality, this static three wheel road roller has a wide range of applications
2. Low gravity center, the static road roller possesses a good stability
3. LTJ18X21 static three wheel road roller has a spacious and comfortable cab, with broad visual field
4. Central articulated hydraulic steering for flexible turning and convenient operation
5. Articulated connection and flexible steering
6. Adopting hydraulic braking, this static three wheel road roller is safe and dependable
7. There is simple chair in the cab and single steering wheels. This static road roller machine has good capacity of stitching hems.
8. The front machine body of the static road roller is narrow, and the turning sight is excellent
9. This static three wheel road roller is equipped with a sprinkling device for evenly sprinkling the water on the surfaces of both front and rear drums
| Main Technical Parameters | |||
| MODEL | LTJ2125 | LTJ1821 | |
| Operating mass | kg | ||
| Without ballast | 21000 | 18000 | |
| With ballast | 24000 | 21000 | |
| Font linear load | N/cm | ||
| Without ballast | 575 | 510 | |
| With ballast | 650 | 565 | |
| Rear linear load | N/cm | ||
| Without ballast | 1200 | 1056 | |
| With ballast | 2300 | 1226 | |
| Travel speed | km/h | ||
| 1st gear | 2.0 | 2.0 | |
| 2nd gear | 4.0 | 4.0 | |
| 3rd gear | 9.6 | 9.6 | |
| Grade ability | % | 20 | 20 |
| Turning radius | mm | ||
| Inside | 3250 | 3250 | |
| Outside | 5570 | 5570 | |
| Steering angle | 。 | 30 | 30 |
| Overall length | mm | 5700 | 5700 |
| Overall width | mm | 2300 | 2300 |
| Overall hieght | mm | 3000 | 3000 |
| Front wheel size | mm | ||
| Width | mm | 1680 | 1680 |
| Diameter | mm | 1500 | 1450 |
| Rear wheel size | mm | ||
| Width | mm | 530 | 530 |
| Diameter | mm | 1700 | 1650 |
| Wheel base | mm | 2945 | 2945 |
| Ground clearance | mm | 370 | 370 |
| Diesel model | 6108G | 6108G | |
| Diesel power | kW | 85 | 85 |
| Diesel speed | r/min | 2000 | 2000 |
| Fuel tank capacity | L | 200 | 200 |
| Electrical voltage | v | 24 | 24 |
| Hydraulic tank capacity | L | 40 | 40 |
