| Item | Unit | XS202J-II |
| Operating weight | kg | 20000 |
| Weight on front drum | kg | 10000 |
| Static linear load | N/cm | 470 |
| Speed range | km/h | Go forward/reverse |
| Speed I | 2.54/2.52 | |
| Speed II | 4.97/4.98 | |
| Speed III | 10.51/- | |
| Theoretical gradeability | % | 30 |
| Min. external turning radius | mm | 6500 |
| Steering angle | ° | ±33 |
| Oscillating angle | ° | ±10 |
| Vibration frequency | Hz | 28 |
| Nominal amplitude (high/low) | mm | 1.9/0.95 |
| Excitation force (high/low amplitude) | kN | 353/245 |
| Drum diameter | mm | 1600 |
| Drum width | mm | 2130 |
| Engine model | Shanghai Diesel Engine D6114ZG2B | |
| Rated power @2000 r/min | kW | 128 |
| Engine oil consumption | g/kW.h | 223 |
| Hydraulic oil tank capacity | L | 170 |
| Fuel tank capacity | L | 240 |
