Description:
This machine equipped with the steering wheel and the driver seat, control comfortable and convenient mechanical all wheel drive, has the bigger grade ability the machine has compact structure, small size, can be used in narrow site compaction work with the steering wheel and the driver seat, comfortable and convenient manipulation
Parameter:
| Type | YZC1 | |
| 0perating mass | kg | 1000 |
| Vibration amplitude | mm | 0.25 |
| Vibration frequency | Hz | 48 |
| Centrifugal force | kN | 15 |
| Max. travel speed | km/h | 2.5 |
| Gradeability | % | 25 |
| Turning radius | mm | 3900 |
| Drum width | mm | 600×405 |
| Wheelbase | mm | 470 |
| Ground clearance | mm | 275 |
| Diesel model | mm | CF186F |
| Diesel power | kW | 5.68 |
| Overall dimensions | mm | 2050×800×1280 |
