| Type | Unit | YZC7 |
| Working mass | kg | 7160 |
| Axle load, front drum | kg | 3630 |
| Axle load, rear drum | kg | 3530 |
| Static linear load (Front/Rear) | N/cm | 247/240 |
| Speed range | km/h | 0~10.5 |
| Theoretical gradeability | % | 30 |
| Min.Outer turning radius | mm | 4800 |
| Min.Clearance | mm | 300 |
| Steering angle | ° | ±38° |
| Oscillating angle | ° | ±11° |
| Frequency | Hz | 48 |
| Nominal amplitude(High/Low) | mm | 0.7/0.35 |
| Centrifugal force@48HzHigh/Low amplitude | kN | 70/35 |
| Centrifugal force@low frequency high amplitude/high frequency low amplitude | kN | — |
| Vibrating drum diameter | mm | 1040 |
| Vibrating drum width | mm | 1450 |
| Engine | ||
| Model | Deutz F4L912 | |
| Type | Air cooling | |
| Rated power | kW | 51@2000r/min |
| Total length | mm | 4545 |
| Total width | mm | 1600 |
| Total height | mm | 3090 |
| Fuel tank capacity | L | 140 |
| Hydraulic oil tank capacity | L | 140 |
| Water tank capacity | L | 325x2 |
| Engine oil consumption | g.kw/h | 235 |
