Parameter
| Classificatory | Item | Unit | Parameter | |
| Outline dimension | Overall length | mm | 15230 | |
| Overall width | mm | 3000 | ||
| Overall height | mm | 3860 | ||
| Mass | Total mass in travel state | kg | 65000 | |
| Travel performance | Travel speed | Max. travel speed | km/h | 75 |
| Min. stable travel speed | km/h | 0.5 | ||
| Turning diameter | Min. turning diameter | m | 24 | |
| Min. turning diameter at boom tip | m | 26.6 | ||
| Power ratio | kW/t | 7.3 | ||
| Min. ground clearance | mm | 310 | ||
| Approach angle | (°) | 23 | ||
| Departure angle | (°) | 15 | ||
| Braking distance (at 30km/h) | m | ≤10 | ||
| Max. grade-ability | ％ | 40 | ||
| Power | Engine rated output | kW/(r/min.) | 324/1800 | |
| Engine rated torque | N.m/(r/min.) | 2100/1200 | ||
Main Technical Data for Lifting Operation
| Classificatory | Item | Unit | Parameter | ||
| Lifting performance | Max. total rated lifting capacity | t | 100 | ||
| Min. rated working radius | m | 3 | |||
| Max. load moment | Base boom | kN.m | 3238 | ||
| Fully extended boom | kN.m | 1670 | |||
| Fully extended boom + Jib | kN.m | 1127 | |||
| Outrigger span | Longitudinal | m | 7.56 | ||
| Lateral | m | 7.6 | |||
| Boom length | Base boom | m | 12.8 | ||
| Fully extended boom | m | 48 | |||
| Fully extended boom + Jib | m | 48 + 18.1 | |||
| Jib offset angle | ° | 0, 15, 30 | |||
| Working speed | Boom elevating time | Boom raising | s | 60 | |
| Boom telescoping time | Full extending / Full retracting | s | 140 | ||
| Max. swing speed | r/min | 2 | |||
| Hoist speed (single line at 4th layer) | Main winch | m/min | 110 | ||
| Aux. winch | m/min | 85 | |||
