Description:
Mend engineering of viscosity and the viscous materials, such as sand, gravel, stabilized soil, asphalt concrete, harsh concrete material compaction, especially suitable for the high grade highway asphalt layer of the final processing, is the construction of high-grade highway, airport, municipal engineering and industrial site high-performance compacting equipment.
Features:
1. Cummins or wood on the engine, the power of powerful, can be adapted to all kinds of bad working environment;
2. Hydraulic walking drive, imported hydraulic plunger pump motor, second stepless variable speed, reduces the surface vibration impact;
3. through the water or wet sand adjustable roller weight and earth than pressure, convenient adjustment range;
4. Electric power sprinkler systems, glass fiber reinforced plastic water tank, multistage water filter, safe and reliable
5. The machine has compact structure, beautiful modelling,
6. Capacious and closed bridge with ventilation and air conditioning.
Parameter:
| Type | LRS235H | LRS226H | YL16G | |
| Max. Operating mass | kg | 35000 | 26000 | 16000 |
| Min. operating mass | kg | 30000 | 16000 | 9000 |
| Max. travel speed | km/h | 11.5 | 20 | 15 |
| Tyre Amount | 5+6 | 5+6 | 4+5 | |
| Tire contact pressure | kPa | 400~530 | 250-420 | 150~300 |
| Min turning Radius | mm | 9000 | 7710 | 7500 |
| Rolling width | mm | 3065 | 2790 | 2255 |
| Wheel overlap | mm | 50 | 50 | 40 |
| Gradeability | % | 20 | 20 | 20 |
| Diesel model | D6114 | Cummins6BT5.9 | Cummins4BTA3.9 | |
| Diesel power | kW | 147 | 110 | 95 |
| Diesel speed | r/min. | 2300 | 2200 | 2400 |
| Overall dimensions(with cabin) | mm | 5524×3065×3270 | 4874×2790×3103 | 4770×2255×3162 |
| Overall dimensions(with canopy) | mm | 4770×2255×3192 |
