| Specifications | |
| Rated Operating Capacity | 1000 |
| Tipping load(Kg) | 2000 |
| Bucket Capacity(m3) | 0.5 |
| Hydraulic Pump Flow(L/min) | 75 |
| Weight(Kg) | 3400 |
| Max.Travel Speed (km/h) | 12 |
| Tire | 12/16.5NHS |
| Fuel/hyd.oil capacity(L) | 80 |
| Overall dimensions(mm) | 3345×1850×2040 |
| Dimensions | |
| A.Height at Maximum Extension | 3780 |
| B.Hinge Pin Height | 3450 |
| F.Width with Bucket | 1900 |
| G.Track Width | 1500 |
| H.Wheelbase | 1020 |
| J.Ground Clearance | 260 |
| K.Dumping Angle | 45° |
| L.Dumping Height | 2900 |
| M.Rollback at ground | 26° |
| N.Angle of departure | 20° |
