| Specifications | |
| Rated Operating Capacity | 750 kg |
| Tipping load(Kg) | 1500 |
| Bucket Capacity(m3) | 0.3 |
| Hydraulic Pump Flow(L/min) | 75L/min |
| Engine power(HP) | 60 |
| Weight(Kg) | 2,9000 |
| Max. Travel Speed (km/h) | 8 km/hr |
| Grade ability(°) | 20° |
| Tire | 28 x 9—15 |
| Fuel/hyd. oil capacity(L) | 75/75L |
| Dimensions | |
| A. Height at Maximum Extension | 3,300 mm |
| B. Hinge Pin Height | 2,810 mm |
| C. Total Height | 1,600 mm |
| D. Length with Bucket | 3,490 mm |
| E. Length without Bucket | 2,900 mm |
| F. Width with Bucket | 1,680 mm |
| G. Track Width | 1,400 mm |
| H. Wheelbase | 991 mm |
| J. Ground Clearance | 150 mm |
| K. Dumping Angle | 40° |
| L. Dumping Height | 1,500 mm |
| M. Maximum Reach | 1,000 mm |
