| Specifications | |
| Rated Operating Capacity | 1500 |
| Tipping load(Kg) | 3000 |
| Bucket Capacity(m3) | 0.6-0.7 |
| Lifting Force(Kg) | 2200 |
| Hydraulic Pump Flow(L/min) | 100/150 |
| Engine power(HP) | 100 |
| Weight(Kg) | 4280 |
| Max.Travel Speed(km/h) | 8/16 |
| Grade ability(°) | 20 |
| Fuel/hyd.oil capacity(L) | 85 |
| Dimensions | |
| A-Height to top of ROPS(mm) | 2110 |
| B-Ground clearance(mm) | 205 |
| C-Max.lift height, at hinge pin(mm) | 2920 |
| E-Length of undercarriage(mm) | 1938 |
| F-Machine length without bucket(mm) | 2676 |
| G-Machine length with bucket(mm) | 3385 |
| H-Machine width(mm) | 1850 |
| I-Track width(mm) | 320 |
| D-Length of track on ground(mm) | 1500 |
