Towing Wrecker Truck
This truck is composed of chassis, lifting device, draught device, hydraulic pressure system, electronic control system, body, toolbox and etc. it can lift, drag and tract the vehicles in the road. This towing wrecker truck can be divided into the towing and lifting integration type, the towing and lifting separation type.
Typical: Dongfeng 153 Towing Wrecker Truck
| Dongfeng 153 towing wrecker truck can be used to drag some large machines whose weight is less than 15t. |
| Item |
Dongfeng 153 towing wrecker truck |
Overall diamension (mm) |
7440×2498×2920 |
| Chassis model |
EQ5160GKJ |
Body diamension (mm) |
×× |
| Mass quality (kg) |
15600 |
Approach angle/departure angle(°) |
32/22,32/20 |
| Rated quality (kg) |
|
Front overhang/rear overhang (mm) |
1250/1860,1250/1950,1250/2700 |
| Kerb quality (kg) |
10705 |
Max. speed(km/h) |
80 |
| Axle load |
5800/9800 |
| Engine Parameter |
| Engine type |
Engine manufacturer |
Displacement(ml) |
Power(kw) |
| ISDe185-30 |
Dongfeng Cummins Engine Co., Ltd. |
6700 |
136 |
| YC6J180-31 |
Guangxi Yuchai Machinery Co., Ltd |
6500 |
132 |
| ISDe180-30 |
Dongfeng Cummins Engine Co., Ltd. |
4500 |
132 |
| YC6J180-33 |
Guangxi Yuchai Machinery Co., Ltd |
6500 |
132 |
| B170-33 |
Dongfeng Cummins Engine Co., Ltd. |
5900 |
125 |
| B190-33 |
Dongfeng Cummins Engine Co., Ltd. |
5900 |
140 |
| Chassis Technical Parameters of Dongfeng 153 Towing Wrecker Truck |
| Chassis model |
EQ5160GKJ |
Batch |
189 |
| Chassis model |
2 |
Fuel type |
Diesel |
| Axles number |
4500,4700,4950 |
Front wheel base(mm) |
1940 |
| Axle distance(mm) |
3 |
Back wheel base(mm) |
1860 |
| Passenger number in cab |
6 |
Spring number |
9/10+8 |
| Tyre number |
9.00-20,9.00R20,10.00-20,10.00R20 |
| Vehicle description |
The lifting weight of this vehicle can reach 4700kg. |
