Dongfeng Tianlong Chemical Liquid Tank Truck

Technical Parameters of Dongfeng Tianlong Chemical Liquid Tank Truck
Item	Dongfeng Tianlong Chemical Liquid Tank Truck	Overall dimension(mm)	11990×2500×3690,3300
Chassis model	DFL1311A3	Body dimension(mm)	××
Total mass(kg)	31000	Approach angle/departure angle(°)	28/12,28/13,28/14
Rated quality (kg)	14935,15000	Front overhang/rear overhang (mm)	1460/2515,1460/2465,1460/2265, 1460/2215,1460/2135
Kerb weight (kg)	15870	Max. speed(km/h)	90
Axle load	6500/6500/18000(double axles)

Chassis Technical Parameters of Dongfeng Tianlong Chemical Liquid Tank Truck
Chassis model	DFL1311A3	Batch	217
Axles number	4	Fuel type	Diessel
Axle distance(mm)	1950+4250+1300,1950+4250+1350,1950+4500+1300, 1950+4500+1350,1950+4500+1430,1850+4600+1430	Front wheel base(mm)	1940/1940,1986/1986
Passenger number in cab	2,3	Back wheel base(mm)	1860/1860
Tyre number	12	Spring number	8/8/10,3/3/4
Tyre size	10.00-20,10.00R20,11.00-20,11.00R20
Vehicle introduction	The body volume: 23.76m3; its size: L 9100, W2400, and H1550. It is suitable to transfer hexane with the density of 660 kg/m3. When the passenger number in the cab is 2, the load quality is 15000 kg.

Engine Parameter of Dongfeng Tianlong Chemical Liquid Tank Truck
Engine type	Engine manufacturer	Displacement(ml)	Power(kw)
ISDe270 30 ISDe245 30 ISLe290       30 L270         30 L290          30 C245          33 C260 33 YC6L270-33 dCi290-30	Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Guangxi Yuchai Machinery Co., Ltd DFM	6700 6700 8900 8900 8900 8300 8300 8424 11120	198 180 213 199 213 180 191 199 213
