Rescue Fire Truck

Rescue Fire Truck (Fire Emergency Ambulance)
This rescue fire truck is also known as fire emergency ambulance. There are all kinds of fire-fighting equipments, special protective equipment for firefighters, fire detectors and so on. It is responsible for the fire fighting work.

Typical:
DONGFENG 153 water tank fire-fighting truck

Product Dongfeng 153 water tank fire-fighting truck
Chassis model EQ1141G7DJ
Payload(kg) 5950
Engine model EQB180-20
Displacement/Power(ml/kw) 5880/132
Actual cubage(m3) Water loading capacity 5.5T

Overall dimension(mm) 7810×2500×3269
Wheelbase(mm) 4500
Transmission 6 gear mechanical transmission, double pole remote control
Steering gear Power steering
Braking system Spring braking
Clutch Uniwafer dry clutch,Dia φ380MM
Front axle End fist type, I-beam structure,5T
Rear axle Ramming welding bridge shell,10T, the reduction ratio 6.5
Frame description Stamping riveting structure, the outer width of frame assembly 861MM
Max section area  250×80×7mm
Cab Non-longheaded cab,whole metal-enclosed,twisted bar type, turntable. three-seat with sleeper, adjustable driver seat
Air-condition Non

Engine model EQB180-20
Type Water-cooling, 6-in-line supercharged inner-cooling diesel engine
Max power(kW) 132
Displacement(ml) 5880
Max torque(N。m) 610
Cylinder diameter/Stroke(mm) 102 /120
Fuel type diesel
Manufacturer Dongfeng Commins Diesel Engine Co.,Ltd

Parameters above mentioned are referential, and our company reserves the right of product improving.
