Description:
This series is heavy three-wheel static grinding roller, mainly suitable for roadbed and road surface engineering of various materials, such as gravel, crushed stone, sand, sand mixture, stabilized soil and asphalt concrete, is the construction of highway and municipal engineering, parking lot and industrial site universal compaction equipment.
Features:
1. British ricardo technology LRC6105 engine, power reserve coefficient,
2. Special roller heavy transmission and drive axle, ensures the machine driven stationarity and reliability;
3. Hydraulic power steering, and three stop running speed;
4. The articulated fuselage, turning radius small, flexible;
5. Large diameter wheel rolling wheel, compaction uniform quality;
6. Electric power sprinkler systems, glass fiber reinforced plastic water tank (select a);
7. High strength new bridge, indoor can be equipped with air conditioning.
Parameter:
| Type | LGS1822B | |
| Max. Operating mass | kg | 22000 |
| Min. operating mass | kg | 18000 |
| Static linear load,rear | N/cm | 920/1100 |
| Static linear load,front | N/cm | 400/500 |
| Max. travel speed | km/h | 9.6 |
| Rolling width | mm | 2300 |
| Wheel overlap | mm | 290×2 |
| Gradeability | % | 20 |
| Turning radius | mm | 6640 |
| Wheelbase | mm | 3330 |
| Ground clearance | mm | 473 |
| Diesel model | LRC6105 | |
| Diesel power | kW | 90 |
| Overall dimensions | mm | 6200×2300×2995 |
