Description:
This series is heavy three-wheel static grinding roller, mainly suitable for roadbed and road surface engineering of various materials, such as gravel, crushed stone, sand, sand mixture, stabilized soil and asphalt concrete, is the construction of highway and municipal engineering, parking lot and industrial site universal compaction equipment.
Features:
1. British ricardo technology LRC6105 engine, power reserve coefficient,
2. Hydraulic power steering, and three stop running speed;
3. Electric power sprinkler systems, glass fiber reinforced plastic water tank;
4. High strength new bridge, with its anti ultraviolet windshield, indoor can be equipped with air conditioner,
5. Bridge centrally-mounted layout, streamline appearance, won two national patents.
Parameter:
| Type | LGU1822 | LGU2124 | |
| Max.Operating mass | kg | 22000 | 24000 |
| Min. operating mass | kg | 18000 | 21000 |
| Static linear load,rear | N/cm | 920/1100 | 1010/1200 |
| Static linear load,front | N/cm | 374/504 | 430/540 |
| Max. travel speed | km/h | 9.6 | 9.6 |
| Rolling width | mm | 2300 | 2300 |
| Wheel overlap | 260×2 | 260×2 | |
| Gradeability | % | 20 | 20 |
| Turning radius | mm | 6780 | 6780 |
| Wheelbase | mm | 3350 | 3350 |
| Ground clearance | mm | 425 | 425 |
| Diesel model | LRC6105 | LRC6105 | |
| Diesel power | kW | 90 | 90 |
| Overall dimensions | mm | 5724×2300×3089 | 5724×2300×3089 |
