Pneumatic Tire Roller LRS1016
| Pneumatic Tire Roller LRS1016 |
| Mechanical driving, equipped with slick tyres whose inflation pressure is adjustable. CUMMINS engine with strong power. Operating weigh: 10-16 tons. |
| Diesel Engine |
| Model |
4BT3.9 |
| Rated Power/Rotational Speed |
75 kW @ 2400 r/min |
|
| Weight |
| Operating Weight (with driver's cab) |
10000-16000 kg |
| Mass Allocated To Front Wheels |
7200 kg |
| Mass Allocated To Rear Wheels |
8800 kg |
|
| Transmission system |
| Forward(1st Gear) |
4.7 km/h |
| Forward(2nd Gear) |
7.98 km/h |
| Forward(3rd Gear) |
14 km/h |
| Reverse(1st Gear) |
4.49 km/h |
| Reverse(2nd Gear) |
10.85 km/h |
| Gradeability |
20% |
|
| Tyres |
| Tyre Quantity (front + rear) |
4+5 |
| Tyre Specifications |
11.00-20.16 |
| Tyre Inflation Pressure |
200-800 kPa |
| Average Specific Ground Pressure |
150-300 kPa |
| Single Tyre Load |
1778 kg |
| Tyre Overlay Width |
40 mm |
| Front Wheel Vertical Float |
±100 mm |
|
| Machine Parameters |
| Rolling Width |
2290 mm |
| Inside Turning Radius |
5210 mm |
| Outside Turning Radius |
7500 mm |
| Axle Base |
3630 mm |
| Wheel Track |
500 mm |
|
| Refilling Capacities |
| Fuel Tank Capacity |
240 L |
| Sprinkler Tank Capacity |
480 L |
|
|
Note: Materials and specifications are subject to change without notice.
